小型石磨如何更换磨片?

来源:http://www.zysmcn.com/发布时间:2020-12-30

石磨是一整可以研磨面粉、豆类粉、荞麦粉的一种机械,现在的面粉,豆类粉大部分都是用现代的机器研磨的,相比于传统的研磨营养价值要低了很

石磨是一整可以研磨面粉、豆类粉、荞麦粉的一种机械,现在的面粉,豆类粉大部分都是用现代的机器研磨的,相比于传统的研磨营养价值要低了很多,随着大家越来越注重养生,很多人员都选择购买家用小型石磨,在家里自己进行研磨,因其体型比较小,研磨出的食物味道比较美味,营养价值比较高,使用方便等优势,受到了广大消费者的追捧,购买的数量也是越来越多了,在石磨设备中比较重要的一个配件是磨片,磨片的作用也是非常大的,针对更换磨片的流程大家了解多少呢?中阳石磨公司针对更换磨片的流程做出了详细的解答。
Stone mill is a kind of machine that can grind flour, bean powder and buckwheat powder. Nowadays, most of flour and bean powder are grinded by modern machines. Compared with traditional grinding, the nutritional value is much lower. As people pay more and more attention to health preservation, many people choose to buy small domestic stone mills and grind them at home. Because of their small size, they can grind them out With the advantages of delicious food, high nutritional value, and easy to use, Zhongyang stone mill company has been sought after by the vast number of consumers, and the number of purchased products is also increasing. One of the more important accessories in the stone mill equipment is the grinding plate, and the role of grinding plate is also very large. How much do you know about the process of changing grinding plate? Zhongyang stone mill company has made a decision on the process of changing grinding plate Detailed answers.
一、打开机器前端的防护罩,取下动磨盘,用螺丝刀拧紧固定磨片的螺丝,取出磨片。
1、 Open the protective cover at the front end of the machine, take down the movable grinding plate, tighten the screw fixing the grinding plate with a screwdriver, and take out the grinding plate.
二、把新的磨片装回旧磨片原来的位置,锁上所有螺丝,但不要拧紧。接下来,观察磨片的内部圆形和设置台阶之间的间隙,观察磨片和电机是否同心,调整所有螺丝,确定没有问题,并逐步拧紧三个螺丝,不能拧紧螺丝,均匀地拧紧螺丝,直到锁紧。只要
2、 Put the new grinding disc back into the original position of the old grinding disc and lock all screws, but do not tighten them. Next, observe the gap between the inner circle of the grinding plate and the setting steps, observe whether the grinding plate and the motor are concentric, adjust all the screws to make sure there is no problem, and gradually tighten the three screws. If the screws cannot be tightened, tighten the screws evenly until they are locked. as long as
三、完成以上步骤后,再按以下步骤操作:
3、 After completing the above steps, follow these steps:
1、将已经更换磨片的动磨片装回磨粉腔,将机体上的调整螺丝以逆时针方式旋转调松,然后盖上机器前盖锁紧。
1. Install the moving grinding plate that has been replaced back into the grinding chamber, rotate the adjusting screw on the machine body in a counterclockwise manner to loosen, and then close the front cover of the machine and lock it.
芝麻酱石磨机
家用小型石磨更换磨片的流程
The process of replacing grinding plate of small domestic stone mill
2、启动家用石磨,按顺时针方式旋紧调整螺丝,至到机器因磨片摩擦发出尖锐声音为止。然后令磨粉机自行空转两分钟后方关闭机器。
2. Start the domestic stone mill and tighten the adjusting screw clockwise until the machine makes a sharp noise due to the friction of the grinding plate. Then turn off the mill after idling for two minutes.
3、然后再次打开机器前端盖,取出动磨盘,仔细观察并触摸动磨盘和静磨盘齿槽之间的摩擦痕迹,看磨盘周围的摩擦痕迹是否均匀分布,摸磨盘周围的温度是否均匀。如果所有的差异都不明显,那么安装是平衡的,并且磨盘已经被成功地更换。
3. Then open the front cover of the machine again, take out the moving grinding plate, carefully observe and touch the friction marks between the teeth of the moving grinding plate and the static grinding plate, see whether the friction marks around the grinding plate are evenly distributed, and touch whether the temperature around the grinding plate is uniform. If all the differences are not obvious, then the installation is balanced and the disc has been successfully replaced.
4、若是摩擦痕迹与触手温度不均匀,则证明家用小型石磨没有安装平衡,需要进行一些补救。此时,购买磨粉机时随机器配送的铜片即可起到作用,若铜片已丢失则可自行寻找其他材料薄片替代,厚度以0.3mm为宜。观察无摩擦痕迹或无温度的地方有多长,然后根据其长度裁剪磨片,稍微旋松相关位置的螺钉,将薄铜片放在家用磨片的底部,调整磨片的中间度,然后拧紧螺钉。温馨提示:动磨片与静磨片均可如此操作。
4. If the friction trace and the temperature of the tentacle are not uniform, it proves that the household small stone mill is not balanced and needs to be remedied. At this time, the copper sheet delivered with the machine when purchasing the grinder can play a role. If the copper sheet has been lost, you can find other material sheet to replace it, and the thickness should be 0.3mm. Observe the length of the place without friction trace or temperature, then cut the grinding plate according to its length, slightly loosen the screw at the relevant position, put the thin copper plate at the bottom of the household grinding plate, adjust the intermediate degree of the grinding plate, and then tighten the screw. Warm tips: both dynamic and static grinding plates can be operated in this way.
5、按原方法再次试机,直至将磨片调整到平衡为止。
5. Test the machine again according to the original method until the grinding plate is adjusted to balance.
6、新磨片更换成功后,可使用新细沙与大米一斤作为磨合新机物料,将其投入漏斗,将调节螺丝调至九分紧程度。然后开机磨合四至五遍即可。
6. After the new grinding plate is replaced successfully, the new fine sand and a jin of rice can be used as the running in materials of the new machine, put them into the funnel, and adjust the adjusting screw to the nine point tight degree. Then turn on and run in four to five times.
7、相关工作完成,可洗净机器,至此宣告更换磨片完成。
7. After the relevant work is completed, the machine can be cleaned, and the replacement of grinding plate is declared to be completed.
